Description
About Huawei QSFP28-100G-PSM4 02311MNM Transceiver Module
Datacom Technologies BD offers the original Huawei QSFP28-100G-PSM4 02311MNM Transceiver Module at the best price in Bangladesh. This high-performance 100G optical module is ideal for data center interconnects, providing reliable and efficient network connectivity. Contact us today for inquiries and purchase.
Huawei 100G 02311MNM Module Specification
| Parameter | Value |
|---|---|
| Part Number | 02311MNM |
| Form Factor | QSFP28 |
| Application Standard | 100GBASE-PSM4 (non-standard) |
| Connector Type | MPO/APC (8-strand or 12-strand, type B, female connector) |
| Optical Fiber Type | SMF |
| Working Case Temperature | 0°C to 70°C (32°F to 158°F) |
| Digital Diagnostic Monitoring (DDM) | Supported |
| Transmission Rate | 100 Gbit/s |
| Target Transmission Distance | Single-mode fiber (G.652): 500 m |
| Transmitter Optical Characteristics | |
| Center Wavelength | 1310 nm |
| Maximum Tx optical power | 2 dBm |
| Minimum Tx optical power | -9.4 dBm |
| Minimum extinction ratio | 3.5 dB |
| Receiver Optical Characteristics | |
| Rx sensitivity (AVG) | -11.35 dBm |
| Overload power (AVG) | 2.2 dBm |
Description
The Huawei QSFP28-100G-PSM4 02311MNM Transceiver Module is a high-performance optical transceiver designed for use in data center and enterprise networks. It supports a transmission rate of 100 Gbps over a maximum distance of 500 meters on single-mode fiber (SMF). The module features an MPO/APC connector and is compliant with the 100GBASE-PSM4 standard.
This transceiver module is equipped with digital diagnostic monitoring (DDM) capabilities, allowing network administrators to monitor the health and performance of the module in real-time. DDM provides valuable information such as optical output power, received optical power, and temperature, enabling proactive maintenance and troubleshooting.
The QSFP28-100G-PSM4 is designed for use in a variety of applications, including high-performance computing (HPC), cloud computing, and storage networks. Its compact form factor and high performance make it an ideal choice for demanding network environments.
Supported/Comparable Models
Huawei QSFP28-100G-LR4 02311KNU: This module is also a 100G QSFP28 transceiver, but it supports a longer distance of 10 km on SMF using the 100GBASE-LR4 standard.
Huawei QSFP28-100G-SR4 02311GBW: This module is a 100G QSFP28 transceiver designed for use with multi-mode fiber (MMF) over a shorter distance of 100 meters.
Third-party compatible modules: Several third-party vendors offer compatible QSFP28-100G-PSM4 modules that may be interchangeable with the Huawei module. However, it is important to ensure compatibility with the specific equipment and network environment before purchasing third-party modules.
Get in Touch with Datacom Technologies (BD)
- 📞 Call/WhatsApp: 01748173213
- ✉ Email: sales@datacomtechbd.com | datacomtechnologiesbd@gmail.com
What is the Price of Huawei QSFP28-100G-PSM4 02311MNM Transceiver Module in Bangladesh?
The latest price of Huawei QSFP28-100G-PSM4 02311MNM Transceiver Module in Bangladesh ranges from 60,000৳ to 125,000৳ (Estimate) per unit, depending on the specific model, features, and warranty. To place an order for your Huawei 100G Transceiver Module, please contact us via call or WhatsApp at (+8801748173213). Alternatively, you can browse our collection of Huawei 100G Transceiver and directly order the one that meets your needs.
