Description
About H3C 40G Transceiver Module (QSFP-40G-SR4-MM850)
The H3C QSFP-40G-SR4-MM850 is a high-performance, cost-effective solution for 40G Ethernet applications. It supports data rates of up to 40Gbps over multimode fiber up to 85 meters. This module is ideal for data center, server, and storage networks.
Datacom Technologies offers the best price for the H3C 40G Transceiver Module in Bangladesh. We are a leading provider of networking solutions and services.
Specification
| Specification | Value |
|---|---|
| Interface Type | QSFP+ |
| Data Rate | 40Gbps |
| Wavelength | 850nm |
| Fiber Type | Multimode Fiber (MMF) |
| Maximum Transmission Distance | 100m |
| Connector Type | MPO-12 |
| Power Consumption | 1.5W Max |
| Operating Temperature | 0°C to 70°C |
| Storage Temperature | -40°C to 85°C |
| Digital Diagnostic Monitoring (DDM) | Supported |
H3C 40G SR4-MM850 Description
The H3C QSFP-40G-SR4-MM850 is a high-performance, cost-effective 40GbE QSFP+ optical transceiver module designed for short-distance data center and high-performance computing applications. It operates at a wavelength of 850nm over multimode fiber (MMF) up to 100 meters. This module supports a data rate of 40Gbps and is compliant with the IEEE 802.3ba 40GBASE-SR4 standard.
Key Features:
High Performance: Delivers high-speed, reliable data transmission at 40Gbps.
Short-Distance Connectivity: Ideal for data center and high-performance computing environments with its 100m transmission distance over MMF.
Cost-Effective: Offers a budget-friendly solution for 40GbE connectivity.
QSFP+ Form Factor: Compact and hot-swappable for easy installation and maintenance.
DDM Functionality: Provides real-time monitoring of key operational parameters.
Applications:
Data Center Interconnects
High-Performance Computing (HPC)
Storage Area Networks (SAN)
Server and Network Equipment
Supported/Comparable Models:
While the H3C QSFP-40G-SR4-MM850 is a specific model, there are other compatible 40G QSFP+ transceiver modules from various vendors that can be used interchangeably. These modules typically share the same specifications and performance characteristics. Some examples of compatible models include:
Cisco QSFP-40G-SR4
Finisar FTLF8528P2CU
Intel X710-DA2a
What is the price of H3C 40G Transceiver Module (QSFP-40G-SR4-MM850) in BD?
The latest price of H3C 40G Transceiver Module (QSFP-40G-SR4-MM850) price in BD starts from Taka 30,000 to Taka 60,000 depending on model, features and Warranty. To order your Transceiver Module , please contact us by call or WhatsApp (+8801748173213). You can also browse our online shop “Datacom Technologies (BD)” and order your Transceiver Module directly.
For a quote, contact Datacom Technologies BD:
Call/WhatsApp: +8801748173213
Email: sales@datacomtechbd.com or datacomtechnologiesbd@gmail.com
Explore other H3C Transceiver Module here.
