Description
Edgecore ET7402-ER4 100G Transceiver 40KM QSFP28
The Edgecore ET7402-ER4 is a high-performance 100G QSFP28 transceiver designed for long-distance data transmission up to 40KM over single-mode fiber. Ideal for data centers, cloud networks, and telecom applications, this module ensures ultra-fast, reliable connectivity with low power consumption. If you’re searching for a dependable 100G long-range transceiver, the Edgecore ET7402-ER4 offers the perfect blend of speed, distance, and efficiency for your network upgrade.
Edgecore ET7402-ER4 Specification
| Specification | Details |
|---|---|
| Form Factor | QSFP28 |
| Data Rate | 100 Gbps |
| Wavelengths | 1295.56 nm, 1300.05 nm, 1304.58 nm, 1309.14 nm |
| Transmission Distance | Up to 40 km with Forward Error Correction (FEC); up to 30 km without FEC |
| Connector Type | Duplex LC |
| Transmitter Type | Cooled LAN WDM EML (Electro-absorption Modulated Laser) |
| Receiver Type | APD (Avalanche Photodiode) |
| Power Consumption | ≤ 4.5 W |
| Operating Temperature | 0°C to 70°C |
| Compliance Standards | QSFP28 MSA, 100GBASE-ER4 Lite, RoHS |
Edgecore ET7402-ER4 Description:
The ET7402-ER4 transceiver is designed to facilitate 100 Gigabit Ethernet links over long distances, making it ideal for applications that require extended reach without compromising on performance. Utilizing four LAN WDM channels at specific wavelengths (1295.56 nm, 1300.05 nm, 1304.58 nm, and 1309.14 nm), the module multiplexes these channels into a single fiber pair, achieving an aggregate data rate of 100 Gbps. One of the standout features of the ET7402-ER4 is its impressive transmission reach. It supports distances up to 30 km on standard single-mode fiber without the need for FEC. For applications requiring even longer distances, enabling FEC on the host system extends the reach up to 40 km. This flexibility ensures that the transceiver can adapt to various network configurations and requirements. The transceiver employs a cooled LAN WDM EML transmitter, known for its stability and performance over extended distances. The receiver side is equipped with an APD, which offers high sensitivity, ensuring reliable data reception even at lower power levels. This combination of advanced transmitter and receiver technologies guarantees optimal performance across the supported distance range. In terms of design, the ET7402-ER4 adheres to the QSFP28 Multi-Source Agreement (MSA) form factor, ensuring compatibility with a wide range of networking equipment. The hot-pluggable nature of the module allows for seamless integration and maintenance, minimizing network disruptions during installation or upgrades. The duplex LC connector interface is a standard choice for single-mode fiber connections, facilitating easy deployment in existing network infrastructures. Power efficiency is another critical aspect of the ET7402-ER4. With a maximum power consumption of 4.5 W, it ensures that energy usage is kept to a minimum, which is particularly important in large-scale data center environments where multiple transceivers are deployed. The module operates within a commercial temperature range of 0°C to 70°C, making it suitable for a variety of environmental conditions. Compliance with industry standards is paramount for ensuring interoperability and reliability. The ET7402-ER4 meets the specifications set out in the QSFP28 MSA and is compliant with the 100GBASE-ER4 Lite standard, guaranteeing compatibility with other compliant devices and systems. Additionally, the module is RoHS compliant, reflecting Edgecore’s commitment to environmentally responsible manufacturing practices. In summary, the Edgecore ET7402-ER4 100G QSFP28 transceiver is a robust and versatile solution for high-speed, long-distance fiber optic communications. Its combination of extended reach, low power consumption, and compliance with industry standards makes it an excellent choice for network operators looking to enhance their infrastructure with reliable and high-performance components. We also offer a full range of Edgecore SFP and QSFP optical transceiver modules including 10G, 25G, 40G, 50G, 100G, 200G, and 400G—each backed by a 1-year warranty.
Get in Touch with Datacom Technologies (BD)
📞 Call/WhatsApp: 01748173213
✉ Email: sales@datacomtechbd.com | datacomtechnologiesbd@gmail.com
What is the price of Edgecore ET7402-ER4 100G Transceiver 40KM QSFP28 in Bangladesh?
The latest price of Edgecore ET7402-ER4 100G Transceiver 40KM QSFP28 in Bangladesh starts from BDT-60,000/= to BDT-95,000/= (Estimated) depending on quantity and warranty. To order your Edgecore QSFP Transceiver, please contact us by call or WhatsApp (+8801748173213). You can also browse our online shop “Datacom Technologies (BD)” and order your Edgecore 100G Transceiver.
