Description
About Cisco SFP-10G-ER Transceiver Modules
Product Description
| Feature | Specification |
|---|---|
| Data Rate | 10 Gigabit per second (Gbps) |
| Standard | 10GBASE-ER |
| Distance | Up to 40 kilometers (km) |
| Wavelength | 1550 nanometers (nm) |
| Fiber Type | Single-mode (SMF) |
| Connector | Duplex LC |
| Other Features | DDM, Hot-swappable, MSA compliant, Low power consumption |
| Parameter | Value |
|---|---|
| Transmit and Receive Wavelength (nm) | 1530 to 1565 |
| Cable Type | 10GBASE-ER 1550nm SMF |
| Core Size (Microns) | G.652 |
| Modal Bandwidth (MHz*km) | – |
| Cable Distance | 40km |
| Transmit Power (dBm) | Max: 4.0, Min: -4.7 |
| Receive Power (dBm) | Max: -1, Min: -15.8 |
| Bail Latch Color | Red |
| Power Consumption (W) | 1.5 |
| Operating Temperature Range | COM |
Description:
Cisco SFP-10G-ER transceiver modules are designed for extended-distance data transmission over single-mode fiber optic cables. They offer a maximum reach of 40 kilometers, making them ideal for connecting geographically dispersed locations or building backbones. These modules operate at a wavelength of 1550nm and support a data rate of 10Gbps, enabling high-speed and reliable data transfer.
Similar to other SFP+ modules, Cisco SFP-10G-ER modules are hot-swappable, allowing for easy installation and removal without disrupting network operations. They also comply with the SFP+ Multi-Source Agreement (MSA), ensuring compatibility with a wide range of networking equipment from various vendors. Additionally, these modules support Digital Diagnostics Monitoring (DDM), which provides real-time monitoring of operational parameters like temperature, voltage, and optical power for proactive maintenance and troubleshooting.
