Description
About Huawei QSFP28-100G-DR Transceiver Module – 02312VSP
Datacom Technologies is a leading provider of networking solutions in Bangladesh. We offer a wide range of high-quality networking products, including the Huawei QSFP28-100G-DR 100G Optical Transceiver Module. This module is designed for high-speed data center interconnect applications, providing reliable and efficient data transmission over distances up to 40km. Contact us today for the best price and expert consultation.
Huawei QSFP28-100G-DR Specification
| Parameter | Value |
|---|---|
| Module Name | QSFP28-100G-DR |
| Part Number | 02312VSP |
| Form Factor | QSFP28 |
| Application Standard/Type | 100GBase-DR |
| Connector Type | LC/DLC |
| Optical Fiber Type | SMF |
| Type of the End Face of the Fiber Ceramic Ferrule | PC or UPC |
| Working Case Temperature (°C) | 0°C to 70°C (32°F to 158°F) |
| DDM Options | Supported |
| Transmission Rate (bit/s) | 100Gbit/s |
| Target Transmission Distance (km) | Single-mode fiber (G.652) (with diameter of 9 μm): 500 m |
| Transmitter Optical Characteristics | |
| Center Wavelength (nm) | 1311 nm |
| Maximum Tx Optical Power (AVG) (dBm) | 4 dBm |
| Minimum Tx Optical Power (AVG) (dBm) | –2.9 dBm |
| Maximum Tx Optical Power (OMA) (dBm) | 4.2 dBm |
| Minimum Tx Optical Power (OMA) (dBm) | -0.8 dBm |
| Minimum Extinction Ratio (dB) | 3.5 dB |
| Receiver Optical Characteristics | |
| Rx Sensitivity (AVG) (dBm) | -5.9 dBm |
| Rx Sensitivity (OMA) (dBm) | Max(-3.9,SECQ-5.3) |
| Overload Power (AVG) (dBm) | 4 dBm |
Description:
The Huawei QSFP28-100G-DR Transceiver Module (02312VSP) is a high-performance optical transceiver designed for use in data center and enterprise networks. It supports the 100GBase-DR standard, enabling data transmission over single-mode fiber (SMF) at distances up to 500 meters.
This module utilizes advanced technology, including parallel optics and electrical signaling, to achieve high data rates and low latency. The QSFP28 form factor provides a compact and reliable solution for high-density deployments.
Key Features:
100G Ethernet Data Rate: Supports 100 Gigabit Ethernet data transmission.
500m Transmission Distance: Capable of transmitting data over single-mode fiber up to 500 meters.
QSFP28 Form Factor: Compact and pluggable form factor for high-density deployments.
Digital Diagnostics Monitoring (DDM): Provides real-time monitoring of key parameters for proactive maintenance.
Wide Operating Temperature Range: Operates reliably in a wide range of environmental conditions.
Supported/Comparable Models:
While the exact specifications may vary slightly, other compatible QSFP28 100G-DR transceiver modules from different vendors may include:
- Cisco QSFP-100G-DR
- Finisar QSFP-100G-DR
- Mellanox ConnectX-5 QSFP28 100G-DR
- Arista Networks QSFP-100G-DR
